Specification :
| Operating System | Linux OS |
| Number of Door | 2 Door |
| Card Capacity | 1,00,000 |
| Fingerprint Capacity | 20,000 |
| Transaction Capacity | 5,00,000 |
| Communication | TCP/IP |
| Numbers of readers Supported | 4* RS-485 Reader or 4*26-bit wiegand reader) |
| Types of readers Supported | 26-bit Wiegand and RS485 Readers |
| Number of Inputs | 6( 2 Exit Device, 2 Door Status, 2 Aux Input) |
| Power Supply | 9.6V - 14.4V DC |
| Operating Temperature | 0℃ to 45℃ |
| Operating Humidity | 20% to 80% RH (Non-condensing) |
| Dimensions (L * W * H) | 185.12 mm*106 mm*36.07 mm |
