Specifications :

EL-600SD	LED, door sensor
Lock size	250Lx48.5Wx25H(mm)
Armature Plate	180Lx38Wx11H(mm)
Holding Force	280kg (600Lbs)
Voltage	DC12V or DC24V (adjustable)
Current Draw	12V/500mA 24V/250mA
Signal Output	Dry Contact, Max Rating of Contact Current 3A
Surface Temp	≤20°C
Operating Temp	-10°C ~ 55°C (14°F~131°F)
Suitable Humidity	0~90%(non-condensing)
Finishes for Magnetic	Zinc
Finishes for Armature	Zinc
Finishes for Shell	Anodized aluminum surface texture processing
Weight	2kg
Standard Packing	10pcs
