Specification :-
| KR500E | 125 KHz Proximity card reader |
| Read Rang | Upto 5 CM |
| Reading Time (Card) | ≤200ms |
| Power/Current | DC6-14V/Max.70mA |
| Connectivity | Wiegand |
| Input Port | 2ea (External LED Control) |
| Output Format | 26 bit Wiegand (default) /34 bit Wiegand (default) |
| LED Indicator | 2 Color LED Indicators (Redand Green) |
| Beeper | Yes |
| Operating Temperature | 20°Cto+65°C |
| Operating Humiditiy | 10% to 90% relative humidity non-condensing |
| Color | Black |
| Dimension (W x H x T) | 116x75x17.3mm |
| Weight | 50g |
