| Model Name/Number |
ET1000 |
| Frequency |
50/60 Hz |
| Passage Width |
520 mm |
| Throughput Rate |
35 p/m |
| Protection Level |
IP44 |
| Brand |
Essl |
| Power Supply |
240V |
| Operational Voltage |
24V |
| Max Power Consumption |
30 W |
| Working Temperature |
-25 Degree C ~ +70 Degree C |
| Electro - Magnetic Drive |
DC |
| Dimension Excluding Bar (in mm) |
(L)480 x (W)280 x (H)980 |
| Net Weight Including Bar |
44kg |
| Availability |
In Stock |
Features:
- Semi-Auto mode
- Pure mechanical mode
- Single or Bi-directional function in mechanical and electrical versions
- Automatic reset of barrier arms after each passage
- Adjustable time out delay
Operating Mode:
- Single passage in the set direction
- Bi-directional passage
- Free passage in the set direction
- Always free or locked Materials
- Housing : SS304
- Barrier Arms : Stainless steel
- Lid (Optional) : Stainless steel or artificial stone(black / brown)
Secondary Controller:
- Users : 30000 (RFID)
- Fingerprint : 3000
- Transaction storage : 100000
- Integrated Controller : inbio-260
- Relay : 12 V relay for lock
- Support Fire Alarm : Yes
Reader:
- RFID : Yes | Fingerprint : Yes
- Protocol : RS485 / Mifare/Proxy (Optional) : Yes
